Conductor
Stranded copper conductor, IEC 60228 class 6
Insulation
PE
Cabling
Two cores in parallel
Sheath
TPU
Standard colour yellow or black, red on request
Standard colour yellow or black, red on request
Application
Halogen Free, flame retardant, field instrumentation cable for fixed and flexible installations.
Designed to withstand marine, offshore and industrial use.
Actuator Sensor Interface (ASI) system is a network system for lowest field level, connecting simple binary ON/OFF devices such as actuators, sensors, analog inputs/outputs, push buttons, valves or signal lamps. The two-core cables provide common data and power transition using a single master system. Within the ASI-modules the conductor is contacted by piercing technology without cutting it, and the special grooved and angled flat sheath shape ensures that installation and connection errors are minimized.
Core identification
1. Blue
2. Brown
2. Brown
Min. Bending Radius (Installation/fixed)
16 mm/24 mm
Nominal Outer Ø
4.0 ± 0.2 mm
10.0 ± 0.2 mm
10.0 ± 0.2 mm
Marine Type Approvals
DNV (pending)
Rated voltage
32 V DC (yellow sheath)
48 V DC (black sheath)
230 V AC (red sheath)
48 V DC (black sheath)
230 V AC (red sheath)
Fire performance
IEC 60332-1-2
Halogen-free
IEC 60754 series
Oil resistance
IEC 60811-404 conditions acc. to EN 50363-10-2
Max. Conductor resistance (DC)
1.5 mm² : 13.7 ohm/km @20°C br>2.5 mm² : 8.21 ohm/km @20°C
Nom. Mutual capacitance (nF/km)
< 80 nF/km
Min. insulation resistance (20 °C)
≥ 1 MΩ/km
Loop inductance (nom.) (mH/km)
0.4 – 1.3 mH/km
Operating temperature
-40 °C to +80 °C
