Conductor
Solid copper conductor
Insulation
PE
Stranding
Conductors twisted together
Sheath
LSZH Thermoplastic
Standard colours light grey, red, blue
Standard colours light grey, red, blue
Reference standard
EN 50288-7
SFS 2751
SFS 2751
Application
Cable for instrumentation, alarm systems, and personal call finders.
For fixed installation.
For fixed installation.
Core identification
1. Blue
2. Yellow
3. White
4. Red
2. Yellow
3. White
4. Red
Min. Bending Radius (Installation/fixed)
15xØ∕10xØ
Rated voltage
75 V
Fire performance
Dca s2, d2, a1
IEC 60332-1-2
IEC 60332-1-2
Min. installation temperature
-5 ° C
Operating temperature
-5 °C – 70 °C
Loop resistance (pair, max 20 °C) (ohm/km)
73.4
Insulation resistance (20 °C) (Mohm/km)
min, > 500
Conductor/Conductor (kV)
2.25 kV
