Conductor
Stranded copper conductor, IEC 60228 / class 2 (class 5 on request)
Insulation
XPLE
Stranding
Parallel Cores (concentric)
Stranded cores (braided)
Extruded Filler (concentric)
Dummy cores (braided)
Stranded cores (braided)
Extruded Filler (concentric)
Dummy cores (braided)
Screen
Concentric conductor 2.5 mm² Braided 6-16 mm²
Sheath
LSZH Thermoplastic
Standard colour black, outer colours on request
Standard colour black, outer colours on request
Reference standard
IEC 60502-1
Application
Flame retardant, screened power supply cable for fixed installations.
Core identification
Brown and blue
Min. Bending Radius (Installation/fixed)
9xØ∕6xØ
Rated voltage
AC 0.6/1 kV (1.2 kV)
DC 0.9/1.5 kV (if voltage to earth does not exceed 0.9 kV)
DC 0.9/1.5 kV (if voltage to earth does not exceed 0.9 kV)
Fire performance
Dca s2, d2, a1
UV resistance
IEC 68-2-5
Halogen-free
IEC 60754 series
Smoke emission
IEC 61034 series
Min. installation temperature
-15 ° C
Operating temperature
-40 °C – 80 °C fixed installation
Max. Conductor temperature
90 °C
